Ringlock Scaffolding System
Ringlock is a modular scaffolding system for heavy-duty access and shoring work. It is used on bridges, flyovers, industrial plants, power stations, high-rise facades, shipyards and event structures. Each vertical has a rosette (ring) welded every 500 mm, and each rosette has 8 holes. Ledgers and diagonal braces lock into these holes with wedge heads and a hammered wedge pin, so up to 8 members can connect at one node at fixed or flexible angles. Ringlock has no loose parts at the joint and needs no nuts or bolts. It erects faster than cuplock and carries higher loads, which suits straight, circular and irregular structures.
Standards (Verticals)
Standards are made from high-tensile steel pipe with rosettes welded at 500 mm intervals and a spigot at one end for vertical extension.
Specification
| Product Code | Length c/c | Weight |
|---|---|---|
| RL-S300 | RL-S300 | 15.3 kg |
| RL-S250 | 2.5 m | 12.9 kg |
| RL-S200 | 2.0 m | 10.5 kg |
| RL-S150 | 1.5 m | 7.9 kg |
| RL-S100 | 1.0 m | 5.4 kg |
| RL-S050 | 0.5 m | 3.0 kg |
Note : Pipe OD 48.3 mm, wall thickness 3.2 mm, grade Q345 / S355 (high tensile). Rosette 8–10 mm thick with 4 small holes for ledgers and 4 large holes for braces. Spigot 60 × 4 mm pipe, fixed with bolt or pin. Standards can be made to any length on request.
Ledgers (Horizontals)
Ledgers have a cast or forged wedge head welded at both ends with a captive wedge pin. The wedge drops into the rosette and one hammer blow locks it.
Specification
| Product Code | Length c/c | Weight |
|---|---|---|
| RL-L240 | RL-L240 | 7.7 kg |
| RL-L180 | 1.8 m | 6.0 kg |
| RL-L150 | 1.5 m | 5.2 kg |
| RL-L120 | 1.2 m | 4.3 kg |
| RL-L090 | 0.9 m | 3.5 kg |
| RL-L060 | 0.6 m | 2.6 kg |
Note : Pipe OD 48.3 mm, wall thickness 2.5 mm. Ledgers can be made to any length on request.
Diagonal Braces
Diagonal braces fit into the large holes of the rosette through swivel brace heads. They give the frame its lateral stability.
Specification
| Product Code | Bay Length × Lift Height | Weight |
|---|---|---|
| RL-D3020 | 3.0 m × 2.0 m | 9.0 kg |
| RL-D2420 | 2.4 m × 2.0 m | 7.9 kg |
| RL-D1820 | 1.8 m × 2.0 m | 7.0 kg |
| RL-D1520 | 1.5 m × 2.0 m | 6.6 kg |
| RL-D1220 | RL-D1220 | 6.2 kg |
Note : Pipe OD 33.7 / 42 mm, wall thickness 2.3 mm, with swivel brace heads at both ends.
Base Collar (Starter)
The base collar is a short tube with one rosette. It sits on the base jack and gives an even, level start to the first lift of standards.
Specification
| Product Code | Length | Weight |
|---|---|---|
| RL-BC | 0.24 m | 0.24 m |
Adjustable Base Jack / U-Head Jack
Base jacks and U-head jacks are thread-rolled from solid bar (32 / 36 mm) or hollow pipe (38 mm dia, 4–5 mm thick). They come with a base plate (150 × 150 × 6 mm) or a U-head (70 × 110 × 70 mm) and fine-tune the scaffold height at the bottom or top.
| Product Code | Length | Weight |
|---|---|---|
| RL-BJ600 | 600 mm | 3.6 kg |
| RL-UJ600 | 600 mm | 4.2 kg |
Note : 450 / 750 mm and custom lengths available on request.
Steel Planks (Hook-on Platforms)
Perforated galvanised steel planks with hooks at both ends rest directly on the ledgers to form a non-slip working platform.
| Product Code | Size | Weight |
|---|---|---|
| RL-P300 | 3.0 m × 240 mm | 15.5 kg |
| RL-P240 | 2.4 m × 240 mm | 12.6 kg |
| RL-P180 | 1.8 m × 240 mm | 9.8 kg |
